| Place of Origin: | China |
|---|---|
| Brand Name: | OEM |
| Certification: | ISO/RoHS/CE |
| Minimum Order Quantity: | 200 meters |
| Price: | Negotiation |
| Packaging Details: | Standard export package |
| Delivery Time: | 15-20 working days or Negotiation |
| Payment Terms: | T/T, L/C, D/P, West Union, Paypal, Secure Payments |
| Supply Ability: | 50000meters per week |
| Conductor Core: | Copper Or Aluminum | Insulation: | Crosslinked Polyethylene (XLPE) |
|---|---|---|---|
| Outer Sheath: | Polyvinyl Chloride (PVC) Or Polyethylene (PE) | Armour Type: | STA/SWA/AWA Armoured Or Unarmoured |
| Voltage: | 600V To 35KV | Cross Section Area: | 0.75mm2-1000mm2 |
| Standard: | IEC60502, BS IEC ASTM DIN, GB/T12706, VDE, UL | Color: | Black (or Customized) |
| High Light: | 35mm2 xlpe power cables,35mm2 4 core xlpe cable,600V low voltage xlpe cable |
||
10mm2 25mm2 35mm2 Anti Chemical Corrosion 4 Core Xlpe Cable
Number of cores:
1 core, 2 core , 3 core , 3+1 core, 3+2 core, 4 core, 4+1 core, 5 core
XLPE Electrical Cables Application:
XLPE insulated electrical cable has more advantages than PVC insulated electrical cable including the characteristics of high electric strength, mechanical strength, anti-chemical corrosion etc. In addition xlpe cable has higher long-term working temperature and current-carrying capacity than PVC cable. So xlpe cable is widely used in indoor, tunnel, canal, power plant etc.
XLPE Electrical Cables Service Characteristics:
1. The long working temperature of xlpe cable should not be higher than 90℃.
2. The temperature should not exceed 250℃ in short-circuit (max. 5s).
3. The ambient temperature should be above 0℃ otherwise the cable should be preheated when installed.
4. Bending radius of cable:
single core cable: 20*(D+d)±5% 2~5 core cable: 15*(D+d)±5%
Remarks: D (overall diameter of cable) d (diameter of conductor)
XLPE Electrical Cable Types:
|
|||||||||||||||||||||||||
