Place of Origin: | China |
---|---|
Brand Name: | OEM |
Certification: | CE,UL& ROHS |
Minimum Order Quantity: | 500 m |
Price: | Negotiation |
Packaging Details: | Standard export package |
Delivery Time: | 15-20 working days or Negotiation |
Payment Terms: | T/T, L/C, D/P, West Union, Paypal, Secure Payments |
Supply Ability: | 5000Km / Month |
Rated Voltage: | 0.6/1 KV | Conductor: | Stranded Bare Copper |
---|---|---|---|
Insulation (1st Layer): | Mica Tape | Insulation: | XLPE |
Delivery Length: | Cut To Length | Sheath: | LZSH |
High Light: | 600V flame retardant cables,70mm2 fire resistant cable,70mm2 fireproof electrical wire |
Two Core Fireproof Electrical Wire Fire Performance Cable With Glass Yarns Filler
This type of cable is made up of single and multi-cores 600/1000V cables Service Temperature 90°C Emergency Overload Temperature 125°C Short-Circuit Temperature 250°C
The design, construction and testing are compliant with international standard IEC60502 and testing standard BS6387,with standing temperatures of 950~1000 °C for 90 minutes, which means they are capable of remaining in working order despite the most extreme fire conditions. Hence they are known as FIRE RESISTANT cables.
— Flame Retardant
— High Operating Temperatures
— LSOH Halogen-free
— Great Mechanical Strength
— Competitive Installed Cost
— Public Places
1.1 GB/T 2951-2008 1.2 GB/T 3048-2007 1.3 BS 6837 |
Conductor | Stranded bear copper |
Insulation (first layer) | mica tape, flame retardant | |
Insulation (second layer) | Halogen-free cross-linked polyethylene (XLPE) |
|
Binder tape | glass-fibre tape | |
Filler | Glass yarns | |
core wraping | glass-fibre tape as flame-protection | |
Inner Sheath | oxygen barrier layer | |
Sheath | Halogen-free thermoplastic polyolefin | |
Service Temperature | 90°C | |
Max. conductor temp. in service | 125°C | |
Short-Circuit Temperature | 250°C |
Nominal cross section
|
Outer Diameter approx. |
Weight of cable approx. |
Voltage drop | Mini bending radius | |
Single phase | Three phase | ||||
mm2 | mm | kg/km | V/A.km | V/A.km | mm |
2 x 1.5 | 10.3 | 251.5 | 30.8 | 26.7 | 154.5 |
2 x 2.5 | 11.1 | 287.4 | 18.9 | 16.4 | 166.5 |
2 x 4 | 12.0 | 349.2 | 11.8 | 10.2 | 180.0 |
2 x 6 | 13.0 | 410.7 | 7.9 | 6.81 | 195.0 |
2 x 10 | 16.3 | 526.4 | 4.7 | 4.05 | 244.5 |
2 x 16 | 18.4 | 679.8 | 2.94 | 2.55 | 276.0 |
2 x 25 | 21.0 | 931.7 | 1.87 | 1.62 | 315.0 |
2 x 35 | 23.7 | 1,164.0 | 1.35 | 1.17 | 355.5 |
2 x 50 | 26.7 | 1,472.0 | 1.01 | 0.87 | 400.5 |
2 x 70 | 30.5 | 1,951.7 | 0.71 | 0.61 | 457.5 |
2 x 95 | 34.6 | 2,613.8 | 0.52 | 0.454 | 519.0 |
2 x 120 | 38.1 | 3,170.6 | 0.43 | 0.371 | 571.5 |
2 x 150 | 42.4 | 3,804.4 | 0.36 | 0.313 | 636.0 |
2 x 185 | 46.2 | 4,671.6 | 0.30 | 0.265 | 693.0 |
2 x 240 | 51.7 | 5,935.3 | 0.26 | 0.222 | 775.5 |
2 x 300 | 57.7 | 7,297.8 | 0.23 | 0.197 | 865.5 |
