| Place of Origin: | China |
|---|---|
| Brand Name: | OEM |
| Certification: | ISO,CE,UL,ROHS |
| Minimum Order Quantity: | 1 METER |
| Price: | Negotiation |
| Packaging Details: | Standard export package |
| Delivery Time: | 15-20 working days or Negotiation |
| Payment Terms: | T/T, L/C, D/P, West Union, Paypal, Secure Payments |
| Supply Ability: | 1000 Kilometer/Kilometers per Week |
| Application: | Telecommunication,Trunk Line,distribution | Installation: | Underground, Direct Burial,duct,RRU |
|---|---|---|---|
| Core: | 24 CORE | Armour: | Aluminum Tape |
| Jacket: | PE | Conductor Material: | Copper |
| Color: | Customized | ||
| High Light: | 15.3mm hybrid fiber cable,24 core hybrid fiber optic cable,15.3mm hybrid fiber power cable |
||
Aluminum Tape Armour Hybrid Fiber Cable Single Mode 24 CORE
Characteristics:
Applications:
Standards: YD/T 2159
Temperature: Storage, transportation and Operating temperature: -40°C~+60°C
GDTS Ⅰ Structural Technical Parameters
| The conductor cross-sectional area(㎡) | Dimension (mm) | Nominal Weight (kg/km) | Permitted Crush (N) | Bend Radius (mm) | |
| Long term | Short term | Static state | |||
| 4 | 15.3 | 325 | 300 | 1000 | 12.5D |
| 6 | 16.5 | 425 | 300 | 1000 | 12.5D |
GDTS Ⅱ Structural Technical Parameters
| The conductor cross-sectional area(㎡) | Dimension (mm) | Nominal Weight (kg/km) | Permitted Crush (N) | Bend Radius (mm) | |
| Long term | Short term | Static state | |||
| 1.5 | 11.8 | 142 | 300 | 1000 | 12.5D |
| 2.5 | 12.9 | 180 | 300 | 1000 | 12.5D |
GDTS Ⅲ Structural Technical Parameters
| The conductor cross-sectional area(㎡) | Dimension (mm) | Nominal Weight (kg/km) | Permitted Crush (N) | Bend Radius (mm) | |
| Long term | Short term | Static state | |||
| 6 | 16.4 | 183 | 300 | 1000 | 12.5D |
Note:
